Form Factor:
4U chassis support for max. motherboard size - 12" x 13" E-ATX
Processor Support:
Supports dual, single Intel / AMD processors
Dimensions:
Height:17.8" (452mm)
Width:7.0" (178mm)
Depth:25.5" (648mm)
Gross Weight:56 lbs (25.4kg)
Available Colors:Black Expansion Slots:
7x Full-height, Full-length PCI expansion slots
Drive Bays:
Hot-swap:
8x 3.5" SAS / SATA Hot-swap Drive Bays
SAS or enterprise SATA HDD only recommended
Peripheral Bay(s) :
3x 5.25" Peripheral Drive Bays
Backplane:
SAS / SATA Hard Drive Backplane Front Panel:
Buttons:Power On/Off button
System Reset button
LEDs:Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Power Fail LED
Ports:2x USB Ports System Cooling:
Fans:
4 5000 RPM Hot-swap PWM Cooling Fans
Rear exhaust fans excluded (for optimized Superquiet System) System Monitoring:
Chassis intrusion switch
Power Supply:
500W AC power supply w/ PFC
AC Voltage:100 - 240V, 50-60Hz, 7-3.5 Amp
+5V:20 Amp
+5V standby:3 Amp
+12V1:17 Amp
+12V2:17 Amp
+12V3:17 Amp
+12V4:18 Amp
-12V:0.5 Amp
+3.3V:15 Amp
Certification: 80 PLUS Bronze Certified Regulatory (Power Supply) :
Power Supply Safety / EMC:
USA - UL listed, FCC
Canada - CUL listed
Germany - TUV Certified
Europe/CE Mark
EN 60950/IEC 60950-Compliant
CCC
Warranty Information :
1 Year
- Manufacturer:
- Model Number:
- ASIN:
- Condition:
- Weight:
- Dimensions:
- Updated:
- Added:
- Supermicro
- CSE-743T-500B
- B003ZU14C0
- New
- 39.68 lbs
-
33 X
25 X
12
-
Sep 04, 2025
-
Feb 18, 2010
