Edgecore 6812-32X-O-AC-F-US Edgecore 6812-32x 32-port 40gbe Qsfp+ Switch

• Ports: 32 QSFP+ fixed ports (40 GbE or 4 x 10 GbE per port)
• Switch Capacity: 32 x 40 GbE
• Management Ports: 1 x RJ-45 serial console, 1 x RJ-45 100/1000BASE-T management port, 1 x USB Type A storage port
• Switch Silicon: Broadcom BCM56860 Trident II+ 1.28 Tbps
• CPU: Intel Atom C2538 quad-core 2.4GHz x86 processor
• Memory: 8 GB SO-DIMM DDR3 RAM with ECC, 16MB SPI flash, 8GB NAND flash, optional mSATA SSD
• Performance: Switching capacity of 1.28 Tbps full duplex, forwarding rate of 1.44 Bpps, and supports jumbo frames up to 9216 Bytes
• Supported Optics: Various cabling options, including 40GBASE-SR4 and 40GBASE-LR4, providing flexibility for connectivity
• Physical Specs: Redundant hot-swappable fans, operating temperature range of 0°C to 40°C, and operating humidity of 5% to 95%
• Software Compatibility: Supports Open Network Install Environment (ONIE) and various network operating systems (NOS)
• Power: Dual redundant, load-sharing PSUs with 370 W max power, and 93% efficiency
• Regulatory Compliance: CE Mark, FCC, and RoHS-6 compliant, with stringent environmental testing
• Dimensions: 27 x 23 x 7 inches
• Weight: 27 lbs
• Warranty: 1 Year
